MIMAKI CJV330 Series - Media Cutter Cleaning

Chapter 7 Maintenance
188
2
Select [Station Maint.] > [Carriage Out] > [Move To Maint. Space], then press the [ENTER] key.
• The carriage moves to the maintenance space.
3
Open the maintenance cover on the left side.
4
Clean the media sensor.
5
Once cleaning is complete, close the cover, then press the [ENTER] key.
Media Cutter Cleaning
Continuing to use a dirty media cutter may cause dust to collect on the head nozzle surface or the cutter
blade to grow dull.
• Avoid touching the cutter blade. Failure to do so may result in injury.
1
On the LOCAL mode screen, select [MENU] > [Maintenance], then press the [ENTER] key.
• The Maintenance menu is displayed.
2
Select [Station Maint.] > [Carriage Out] > [Move To Platen Right End], then press the [ENTER]
key.
• The carriage moves over the platen.
3
Open the front cover.
• The carriage can be moved by hand. Move the carriage slowly to a position allowing easy
access while working.
4
Remove the media cutter.
Screw
