Chapter 5 Using the XY Slitter
127
Try the following if the print length is 600 mm or less and the prints do not fall consistently into
the media chute.
• Pattern 1: Close the front of the media chute and secure it with screws. (Use the media
support.)
• Pattern 2: If problems occur when arranged as described above, turn the media chute
around so that the front is at the rear. (Do not use the media support.)
If the prints make contact with the media chute, move the media chute closer to the
machine.
5
