Chapter 8 Troubleshooting
236
Error
number
Message Cause Corrective action
402 Motor Y • The Y motor was
overloaded.
2. Open the front cover and check for
anything that may obstruct carriage
movement.
3. Turn off the power on the machine and
turn it on after a while.
403 X Current • An overcurrent error was
detected in the X motor.
404 Y Current • An overcurrent error was
detected in the Y motor.
406 Wiper Move Failure • The wiper origin could not
be detected.
• Turn off the power on the machine
and turn it on after a while.
44f Take-up Roll Sns Err • A problem was detected
with the take-up unit
sensor spindle.
1. Check to confirm the [Function Setting]
> [Take-up Unit] setting is "ON".
2. Check to confirm the media is loaded
correctly. "Loading the Roll
Media"(P. 67)
3. Check to confirm the take-up unit switch
functions properly. "Take-up
Unit"(P. 60)
45a Failed Cutter unit joint • The carriage could not be
disconnected.
• Turn off the power on the machine
and turn it on after a while.
45b Failed Cutter unit
detach
• Unable to connect to
carriage
45e Check PR/GR Position • A problem was detected
with the pinch roller
positions.
• Place the pinch rollers above the
grit rollers.
47f Take-up Diameter Max • The take-up unit media
diameter has reached the
maximum value.
1. Replace the paper core in the take-up
unit.
48a Detect winding failure • A problem was detected
with the take-up unit.
1. Check to confirm the [Function Setting]
> [Take-up Unit] setting is "ON".
2. Check to confirm the media is loaded
correctly. "Loading the Roll
Media"(P. 67)
3. Check to confirm the take-up unit switch
functions properly. "Take-up
Unit"(P. 60)
48b Y MOTOR COM • Y motor communication is
not possible.
1. Close the front cover and maintenance
covers before starting the machine.
48f XYSlitter
MOTOR X
• The X motor of the XY
slitter was overloaded.
1. Lower the XY clamp lever (unclamp).
"XY Clamp Lever"(P. 123)
2. Check to confirm the media is loaded
correctly. "Loading the
media"(P. 130)
3. Check to confirm that the XY slitter X
cutter is correctly mounted.
"Mounting the X cutter"(P. 136)
4. Raise the XY clamp lever (clamp).
491 XYSlitter
X CURRENT
• An overcurrent was
detected in the X motor of
the XY slitter.
490 XYSlitter
MOTOR Y
• The Y motor of the XY
slitter was overloaded.
492 XYSlitter
Y CURRENT
• An overcurrent was
detected in the Y motor of
the XY slitter.
493 XYSlitter
TBar Abnormal
• A problem was detected
with position control of the
XY slitter tension bar.
1. Lower the XY clamp lever (unclamp).
"XY Clamp Lever"(P. 123)
494 XYSlitter
TBar Position
