Chapter 1 Before Use
27
No. Name Overview
12 Media edge guides
* TS only
In some cases, roll media may shift sideways and start to curl inwards.
Using the media edge guides prevents the roll media from becoming offset.
"Using the Media Edge Guides"(P. 63)
13 Post-heater Allows ink to dry after printing. Adjust the temperature setting to suit the type
of media used. "Setting the Heater Temperature"(P. 78)
14 Front cover Open the cover for loading the media, performing maintenance on the area
around the platen, and for replacing consumable items. Printing and
automatic maintenance are not possible while the covers are open.
1
To Next Page
