MIMAKI JV5 Series Maintenance Manual

© 2009 MIMAKI ENGINEERING CO.,LTD.
6.5.10 P.2
6.5.10 Cutter Slider PCB Assy
1
2
3
4
5
6
7
8
3. Remove the screw, release the hook and then remove cutter
slider PCB assy.
4. Reverse the disassembly procedure for reassembly.
Cutter Slider PCB Assy
Screw
Releasing of the hook
R.1.0
Maintenance Manual > Disassembly and Reassembly > Electrical Parts > Cutter Slider PCB Assy
Model CJV30/TPC Issued 2008.08.04 Revised 2008.09.17 F/W ver. 1.20 Remark
1.0
Rev.
