MIMAKI JV5 Series Maintenance Manual

© 2009 MIMAKI ENGINEERING CO.,LTD.
6.6.1 P.1
1
2
3
4
5
6
7
8
R.1.1
Maintenance Manual > Disassembly and Reassembly > Sensors > Sensor Layout
Model CJV30/TPC Issued 2008.08.04 Revised 2008.09.17 F/W ver. 1.20 Remark
1.1
Rev.
6.6.1 Sensor Layout
Detector Assy, I/C, Y (x8)
LED Pointer
Cartridge Near End
Sensor (x8)
Paper Sensor
Y-origin Sensor
Wiper Origin Sensor
Clamp Sensor
Cartridge Near End
Sensor (x8)
Detector Assy, I/C, Y (x8)
Linear Encoder
Head Height Sensor
Mark Sensor
Joint Sensor
PR Sensor
