MIMAKI JV5 Series Maintenance Manual

© 2009 MIMAKI ENGINEERING CO.,LTD.
7.1.3 P.3
7.1.3 List of Warning Messages
1
2
3
4
5
6
7
8
 List of Warning Messages (3/3)
Possible to confirm warning below on local guidance
LOCAL> [ENTER](ink remaining quantity is displayed)>[FUNCTION]
No. Indication on LCD Cause Remedy
34
INK NEAR END
Ink in the cartridge is running out. (Print or use-up cleaning is available)
35
INK END
The ink of the ink cartridge has been
completely used up.
(Use-up cleaning is available)
36
NON-ORIGINAL INK
The ink cartridge is not MIMAKI genu-
ine.
Replace the cartridge generating the warning with a new one.
If the problem still cannot be solved, check the followings.
1. Check whether the process of [#TEST] -> [INK
CARTRIDGE] -> [INK-IC CHECK] can be carried out
normally.
2. ID Contact PCB CN032 Assy. (See 6.5.15)
37
WRONG INK IC
The IC chip of the ink cartridge cannot be
read normally.
38
Kind of INK
It is different types of ink from the ink
filling up with the machine.
Check the ink type of the cartridge generating the warning.
39
Color of INK
It is not the color should be installed. Check the ink color of the cartridge generating the warning.
40
WRONG CARTRIDGE
There is trouble with an installed ink car-
tridge.
Check the cartridge generating the warning.
41
NO CARTRIDGE
An ink cartridge has not been installed in
the slot.
Install an appropriate ink cartridge in the slot generating the
warning. If the problem still cannot be solved, check the fol-
lowings.
1. Check that the cartridge exist/non-exist sensor functions
properly with [#TEST] -> [INK CARTRIDGE].
2. If it does not work properly, replace the sensor or X-axis
motor relay PCB assy with a new one.
42
Expiration
The specified expiration date of an ink
cartridge has passed.
Make sure if the month of machine is correct on [MACHINE
SETUP2]>[TIME SET] if the Warning is displayed within
expiry month described on cartridge.
Refer to 1.3.10 Expiry month and extension of expiry month
for ink
43
Expiration:1MONTH
The specified expiration date of an ink
cartridge has passed. (One month has
passed after the specified expiration
date.)
44
Expiration:2MONTH
The specified expiration date of an ink
cartridge has passed. (Two months have
passed after the specified expiration
date.)
45
COMPLETELY EXPIRED
The specified expiratio date of ink car-
tridge has passed. (Six month has passed
after the specified expiration date.)
Not extend expiry month.
46
EXPIRED INK IN USE
Cartridge extended expiry month.
47
INK REMAIN ZERO
---- ----
Remaining amount of ink in an ink car-
tridge is zero.
(Used the prescribed quantity of use-up
cleaning.)
Replace the cartridge generating the warning with a new one.
48
REINSERT CARTRIDGE
The end sensor was detected even though
enough quantity was remaining.
Install appropriate cartridge. If the warning is not hidden,
check or replace the sensor on [#TEST]>[INK CAR-
TRIDGE].
49
Check the “W”nozzle
condition. <ENT>
When SS 21 white ink is used, the mes-
sage of prompting you to perform test
printing is displayed for keeping the noz-
zle status be normal.
Perform “WHITE CHK.” of test printing.
50
PERFORM SPOT COLOR
MAINTENANCE? <ENT>
When silver and white ink of ES3 ink are
used, the message of prompting you to
perform special color maintenance for
preventing color heterogeneity due to set-
tling down of pigment is displayed.
Perform spot color maintenance.
R.1.3
Maintenance Manual > Troubleshooting > Details on Errors and Malfunctions > List of Warning Messages
Model CJV30/TPC Issued 2008.08.04 Revised 2010.11.05 F/W ver. 2.50 Remark
1.3
Rev.
