MIMAKI UCJV300-160 User Manual

Chapter 2 Printing
55
1,600 mm size
1577 ~ 1620mm
1446 ~ 1514mm
1212 ~ 1272mm
1032 ~ 1092mm
732 ~ 792mm
576 ~ 644mm
364 ~ 424mm
241 ~ 301mm
1501 ~ 1561mm
1370 ~ 1438mm
1136 ~ 1196mm
956 ~ 1016mm
656 ~ 716mm
500 ~ 568mm
288 ~ 348mm
165 ~ 225mm
1413 ~ 1473mm
1284 ~ 1350mm
1048 ~ 1108mm
868 ~ 928mm
568 ~ 628mm
414 ~ 480mm
200 ~ 260mm
85 ~ 137mm
GR1
GR2GR4
GR3
GR11 GR10 GR5GR6GR7GR8GR9
Choose the grit rollers based on media width.
GR: Grit roller
Set the right edge of the media
so that it falls within this range.
2

MIMAKI UCJV300-160 Specifications

General

Maximum Print Width	1, 610 mm
Resolution	1200 x 1200 dpi
Ink Type	UV-curable ink
Cutting Function	Yes
Media Thickness	Up to 1 mm (0.04")
Media Width	1, 620 mm (63.8")
Connectivity	USB2.0, Ethernet
Print Speed	Up to 25.8 m²/h
Print Technology	UV-LED Inkjet
