MIMAKI UCJV300-160 User Manual

Chapter 2 Printing
57
1,070 mm size
1043 ~ 1100mm
900 ~ 960mm
732 ~ 792mm
576 ~ 644mm
362 ~ 422mm
241 ~ 301mm
967 ~ 1027mm
824 ~ 884mm
656 ~ 716mm
500 ~ 568mm
288 ~ 348mm
165 ~ 225mm
879 ~ 939mm
736 ~ 796mm
568 ~ 628mm
414 ~ 480mm
200 ~ 260mm
85 ~ 137mm
GR1
GR2GR4
GR3
GR5GR6GR7GR8GR9
GR: Grit roller
Choose the grit rollers based on
media width.
Set the right edge of the media so that it falls
within this range.
2

MIMAKI UCJV300-160 Specifications

General

Maximum Print Width	1, 610 mm
Resolution	1200 x 1200 dpi
Ink Type	UV-curable ink
Cutting Function	Yes
Media Thickness	Up to 1 mm (0.04")
Media Width	1, 620 mm (63.8")
Connectivity	USB2.0, Ethernet
Print Speed	Up to 25.8 m²/h
Print Technology	UV-LED Inkjet
