MIMAKI UJV100-160 - Cap Replacement

3. Consumable Item Replacement
21
7
Mount a new wiper.
Lug
8
Once replacement is complete, close the cover, then press the [ENTER] key.
• The wiper usage count is reset.
Cap Replacement
If ejection failures (e.g., nozzle clogging or deflection) remain unresolved even after cleaning, replace with a
new cap.
• Be sure to replace the cap if you observe any scratches or other damage on the rim.
1
On the LOCAL mode screen, select [MENU] > [Maintenance], then press the [ENTER] key.
• The Maintenance menu is displayed.
2
Select [Station] > [Carriage Out] > [Move To Platen Right End], then press the [ENTER] key.
• The carriage moves over the platen.
3
Open the front cover.
4
Remove the cap.
• Squeeze the lugs on either side of the cap and pull off.
