4
Mounting
• PCM4 components are sensitive to electrostatic fields. Avoid
contact with the circuit board directly.
• Protect the PCM4 from dirt, moisture, and accidental
contact. Provide sufficient room for access to the terminal
block.
• Mount the PCM4 away from other heat sources. Operate
within the specified ambient operating temperature range.
The operating temperature range for the PCM4 is 0°C
through 50°C.
• Prevent loose connections by avoiding excessive vibration of
the process control module board.
• Mount the PCM4 in either a horizontal or vertical plane.
• The PCM4 is mounted using 4 – 0.25 inch [6mm] standoffs.
See Figure 1, page 2 for the physical locations of these
standoffs. Use #8 panhead screws to fasten the standoffs to
the mounting surface.
Warning
Do not install, rewire, or remove this control with input
power applied. Doing so may cause fire or serious injury.
Make sure you have read and understood the Safety
Warnings before attempting installation.
m
Installation
