Minarik PCM4 - Dimensions; Figure 1. Process Control Module (PCM4) Dimensions

2
Dimensions
C507
P501
C504
IC504
IC503
TB502
MODEL PCM4
2.1 WATTS
120/240 VAC
TB501
1
T501
+15
INPUT ADJ
SIGNAL
65
C508
-15
C501
C502
C506
IC502
C503
C505
IC501
INPUT 1
7 8
COM
SW501
R501
9 10
INPUT 2 TP
IC505
10-50MA 4-20MA 1-5MA
P502P503
OUT
MAX
OUT
MIN
21
0-±10VDC OUTPUT
R
R
1 2 3
WWW.MINARIKCORP.COM
1.93 [49]
2.70 [69]
4.83 [123]
0.35 [9]
1.30 [33]
4.22 [107]
4x 0.25 [6] STANDOFF
USE #8 PANHEAD SCREWS
Figure 1. Process Control Module (PCM4) Dimensions
ALL DIMENSIONS IN INCHES [MILLIMETERS]
4.83 [123]
1.93 [49]
2.70 [69]
1.30 [33]
0.35 [9]
4.22 [107]
4 x 0.25 [6] STANDOFF
USE #8 PANHEAD SCREWS
