8
Installation
AC line connections
When operating on 120 VAC, leave the jumper bars installed
between terminals 1 and 2 and between 3 and 4 (see Figure 3).
This is how the unit is shipped from the factory. When operating
on 230VAC, remove both jumper bars and place one jumper bar
between terminals 2 and 3 (see Figure 4).
Connect the AC power leads to terminals 1 and 4.
Warning
Do not connect this equipment with power applied.
Failure to heed this directive may result in fire or
serious injury.
Minarik strongly recommends the installation of a
master power switch in the voltage input line. The
switch contacts should be rated at 2 amps AC and
250 volts.
m
Connections
