Minarik PCM4 - Specifications

1
Specifications
Power Requirements
Line input 120/240 VAC, 50/60 Hz, single phase
Input Signal Ranges (input circuit is isolated)
Voltage signal
Narrow range –25 to +25 VDC
Wide range –250 to +250 VDC
Current signal 1–5 mADC, 4–20 mADC, 10–50 mADC
Input Impedance
Voltage signal >25K ohms
Current signal
1–5 mADC 1K ohm
4–20 mADC 235 ohms
10–50 mADC 100 ohms
Output
Impedance 800 ohms
Voltage range, max –10 to +10 VDC
Linearity 0.01%
Operating Temperature Range 0 – 50 °C
