Minarik PCM4 - Figure 6. Unidirectional Manual Master Signal Source Connection; Figure 7. Bidirectional Manual Master Signal Source Connection

13
Figure 7. Bidirectional Manual Master Signal Source Connection
C504
TB501
+15
65
-15 INPUT 1
7 8
COM
9
INPUT 2
-
10K OHM
SPEED ADJUST
POTENTIOMETER
(NOT PROVIDED)
+
Figure 6. Unidirectional Manual Master Signal Source Connection
C504
+15
65
-15 INPUT 1
7 8
COM
9 10
INPUT 2 TP
CW
10K OHM
SPEED ADJUST
POTENTIOMETER
(NOT PROVIDED)
Installation
10K OHM
SPEED ADJUST
POTENTIOMETER
(NOT PROVIDED)
10K OHM
SPEED ADJUST
POTENTIOMETER
(NOT PROVIDED)
-
+
CW
