• Use 18-24 AWG wire for signal wiring. Use 16-18 AWG wire
for AC line (L1, L2) wiring.
Installation
Warning
Do not install, remove, or rewire this equipment with power
applied. Failure to heed this warning may result in fire,
explosion, or serious injury.
Circuit potentials are at 120 or 240 VAC above ground. To
prevent the risk of injury or fatality, avoid direct contact with
the printed circuit board or with circuit elements.
m
(
Wiring
