iv
Figure 1. Process Control Module (PCM4) Dimensions . . . . . . . . . .2
Figure 2. Screw Terminal Block . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Figure 3. 115 VAC Power Connection . . . . . . . . . . . . . . . . . . . . . . .9
Figure 4. 230 VAC Power Connection . . . . . . . . . . . . . . . . . . . . . . .9
Figure 5. Connection – Following an External Signal . . . . . . . . . . .10
Figure 6. Unidirectional Manual Master Signal Source Connection .13
Figure 7. Bidirectional Manual Master Signal Source Connection . .13
Figure 8. Connection – Output Voltage . . . . . . . . . . . . . . . . . . . . . .16
Figure 9. Connection – Multiple Follower System . . . . . . . . . . . . . .18
Figure 10. Signal Input Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Figure 11. Connection – Ratio Potentiometers Multiple
Follower System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Figure 12. SIGNAL INPUT ADJ - Calibration Positions . . . . . . . . . .22
Figure 13. DIP Switch Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Illustrations
