Mindeo ME5066 - Technical Specifications

1
1-2 Technical specifications
Dimensions
H × W × D： 6.8 mm × 23.5 mm × 16.2 mm
Weight
3.5 g
Interface
MIPI
Scan Mode
Command, Level
Cable
34 Pin FPC
Input Voltage
3.3 ± 5% VDC
Current
VIN_3V3_IMGR (Average)
Scanning: 84mA
Standby: 27mA
VIN_3V3_LED (Average)
Scanning: 388mA
Standby: 353μA
Illumination LED
White LED
Aiming LED
Green LED，wavelength: 525 nm
Image Size
1280×1024 pixels
Field of View
Sensor 1: Horizontal: 48°，vertical: 41°
Sensor 2: Horizontal: 26°，vertical: 22°
Scanning Angle
±70°，±75°，360° (Skew, Pitch, Roll)
Print Contrast
20% minimum reflectance difference
Minimum Resolution
1D (Code 39): 3 mil
Decoding Capability
1D: UPC-A, UPC-E, UPC-E1, EAN-13, EAN-8, ISBN (Bookland EAN),
ISSN, Code 39, Code 39 full ASCII, Code 32, Trioptic Code 39, Interleaved
2 of 5, Industrial 2 of 5 (Discrete 2 of 5), Matrix 2 of 5, Codabar (NW7), Code
128, UCC/EAN 128, ISBT 128, Code 93, Code 11 (USD-8), MSI/Plessey,
UK/Plessey, China Post, GS1 DataBar(GS1 DataBar Truncated), GS1
DataBar Limited, GS1 DataBar Expanded
2D: PDF417, MicroPDF417, QR Code, Aztec Code, HanXin Code,
DataMatrix, Micro QR, Codablock F Code, Maxicode
Decoding Depth
3 mil Code 39 (3 chars)
50 – 100 mm
5 mil Code 39 (3 chars)
38 – 250 mm
10 mil Code 39 (3 chars)
25 – 480 mm
13 mil UPC (6 chars)
25 – 630 mm
20 mil Code 39 (1 char)
30 – 880 mm
10 mil QR (20 chars)
30 – 340 mm
10 mil DM (20 chars)
30 – 330 mm
20 mil QR (150 chars)
35 – 600 mm
Temperature
Operating: -20℃ to 50℃（-13℉ to 122℉）
Storage: -40℃ to 85℃（-40℉ to 185℉）
Humidity
5% to 95% (non-condensing)
Mechanical Vibration
IEC60068-2-6
Un-powered engine withstands a random vibration along each of the X, Y
and Z axes for a period of one hour per axis, define as follows:
20 to 80 Hz, Ramp up to 0.04 G2/Hz at the rate of 3 dB/oct;
80 to 350 Hz, 0.04G2/Hz；
350 Hz to 2000 Hz, Ramp down at the rate of 3 dB/oct
