7-26 BeneVision N17/BeneVision N15/BeneVision N12 Patient Monitor Service Manual
7.3.9 iView Module Assembly (115-050002-00)
7.3.9.1 Exploded View
7.3.9.2 Parts List
ITEM No. Description Qty FRU Part No.
1 N17 heat sink (iView or independent display) 1 041-026485-01
2 IVIEW CPU heat conducting pad 1 /
3 IVIEW memory heat conducting pad 4 /
4 Cross recessed pan head screw, M2X6 4 /
