BeneVision N17/BeneVision N15/BeneVision N12 Patient Monitor Service Manual 2-1
2 Operation Theory
2.1 Overview
As a bedside workstation for multi-parameter monitoring, the N series can provide the complete patient
management, abundant physiological parameter monitoring and physiological alarm functions, as well
the powerful data review function and the flexible wired and wireless network configuration and
application capabilities. The third-party application can be accessed easily through the iView application,
meeting the increasingly common information requirements of hospitals. The provided series of CAA
applications can help doctors to make auxiliary diagnosis for patients. Meanwhile, the N series provide the
hospital management personnel with more excellent monitor management applications, rendering
assistance in fixing the efficiency and quality problems during monitor equipment management of
hospitals.
The N series provide the product models with display screens of different sizes according to the demand
of clinical application. In addition to touch screen operations, the user can use the mouse and keyboard to
operate the monitor. The N series can connect to multiple display screens to function as mirror screens or
extension screens.
The series of products are compatible with the BeneView T series plug-in modules and related accessory
products. They can work together with the TDS to implement the intra-hospital transfer application of
patients.
In comparison with the BeneView T series products, the N series boast better human-computer
interaction design and clinical applicability, more complete IT solution capability of hospitals, and more
abundant CDS applications.
2.2 Product System Architecture
All the N17/N15/N12 monitors have only one main unit:

The N12 main unit uses the 12.1” TFT WXGA display screen.

The N15 main unit uses the 15.6” TFT FHD display screen.
 The N17 main unit uses the 18.5”TFT FHD display screen.
 All of them use the touch screen as an input device and can extend the mouse, keyboard and
remote control.

An internal module rack is integrated, with 4 slots (N12) or 6 slots (N15/N17).
 The MPAN and WiFi modules are optional.
 The built-in recorder is optional.

The N15/N17 can connect to the external module rack and TDS; the N12 can connect to the
TDS.
