Electrical Safety Inspection

A-13

ELECTRICAL SAFETY INSPECTION

7- Mains on Applied Part Leakage



5) Select thedesired outlet configurationand applied part to test using theappropriate SOFT

KEYS:

6) PressSTARTTEST(SOFTKEY1)tobeginthetest.

7) Presstheprintdatakeytogenerateaprintoutofthelatestmeasurement.

 Note

If all of theapplied parts correspondto the instrumenttype, the appliedparts will be tied

together and one reading will be taken. If any of the applied parts differ from the instrument

type,allappliedpartswillbetestedindividually,basedonthetypeofappliedpart.Thisapplies

to

AutoandStepmodesonly.

 Failure

Check any broken of the AC/DC adapter and its cable. Replace a new one if any portion

defective.

Checkanybrokenoftheenclosure.Replaceanydefectivepart.

Inspectwiringforbadcrimps,poorconnections,ordamage.

Testthewalloutlet;verifyitisgroundedandisfreeofotherwiring

abnormalities.Notifythe

userorownertocorrectanydeviations.Asaworkaround,checktheotheroutletstoseeifthey

couldbeusedinstead.

Changeanotherprobetoconfirmifthefailiscausedbyconsole.

Inspectwiringforbadcrimps,poorconnections,ordamage.

If the leakage

current measurement tests fail on a new unit and if situation can not be

corrected, submit a Safety Failure Report to document the system problem. Remove unit  from

operation.

If all else fails, stop using and inform the Customer Service Engineer for analysis and 

disposal.

LIMITS

USA：

For

ECG Input and ECG Input and transducer

50μA

OTHER COUNTRIES：
