Disassembly of DP-9900Plus/DP-9900
3-6
3.5. Disassembly of CD-ROM
3.5.1. Locking Casters
1. Press the two casters on the front of the system to lock them.
3.5.2. Disassembly of Drawer and Transducer Cable Hanger
1. Release the four M4×8 screws and remove the drawer.
2. Rotate the transducer cable hanger clockwise until it can be pulled out.
M3×6 Screws
TGC Board
To Next Page
