Structure and Assembly/Disassembly 9-83

4. Unscrew 4 M4 X 12 screws (2 screws on each side) with the screwdriver (M3, M4) to remove

two caster bearings and two front transmitting bearings.

Note:

Place two back rotating bearings level when installing them.

Back transmitting

bearing (2)

Caster bearing (2)

Table of Contents3
