Mindray Passport 12 Service Manual

Passport 8/12 Service Manual 7-13
2. For other modules, unscrew the two M3×6 screws on the back to separate the front and rear housing.
7.5.3 Removing the External Module Interface Board
Unscrew the two M3×6 screws, disconnect all the cables from the board, and then remove the module interface
board.
7.5.4 Removing M03B Module
Disconnect all the cables from the M03B module and push the clamp on the bracket to remove the M03B module.

Mindray Passport 12 Specifications

General

Brand	Mindray
Model	Passport 12
Category	Medical Equipment
Language	English
