Mindray TE7T User Manual

12-8 Setup
Controls are as follows:
Type
Item
Description
Reset Config.
Probe
To set the default probe model for the system.
Use the default
setting when start a
new exam
After it is ticked, when the exam of a new patient is
started, image parameters will be preset parameters.
Probe/Exam
mode
MITI
To set MI TI indexes displayed for current probe/exam
mode.
Freeze Config
Status after Freeze
To set the system status after the image is frozen.
Steer
To set the steer mode in B + Color + PW imaging mode.
C&PW: select to adjust the sample volume in color
mode and sample line in PW mode together.
C/PW: select to adjust the sample volume in color mode
and sample line in PW mode separately.
Auto Invert
The spectrum can automatically invert when the color
flow is steered to a certain angle, thus accommodating
the operator’s wish to distinguish the flow direction.
B+Color Refresh
with PW/CW
Sampling Line
Movement
To set whether to turn on the function that when moving
PW/CW sampling line, B image is activated under
B+Color+PW/CW mode.
Full Image(Linear)
After it is ticked, if a linear probe is used and the depth
value is low, the image will be displayed completely.
iScape Ruler Display
To set if the caliper is displayed on the iScape view
image.
Display Probe SN
To set if the probe SN is displayed next to the probe
model.
12.1.4 Measure
See the Operator’s Manual [Advanced Volume] for details.
12.1.5 OB
See the Operator’s Manual [Advanced Volume] for details.
12.1.6 Footswitch
You can assign a function to the left/middle/right key of the foot switch here.
