13-52 Probes and Biopsy
5. Store or transport the needle-guided bracket under the following ambient conditions:
Ambient temperature: -20°C to 55°C
Relative humidity: 30% to 85% (no condensation)
13.2.10 Disposal
Be sure to sterilize the needle-guided bracket before disposing of it.
Contact your MINDRAY representative when disposing of this device.
13.3 Middle Line
Middle Line helps to locate and observe the focus point of lithotripsy wave during lithotripsy
treatment. By means of providing information for the lithotripsy machine as well as a tool for
watching the procedure of lithotripsy in real-time, you can adjust the intension and frequency of the
lithotripsy wave through lithotripsy machine.
This function in the ultrasound system is for lesion (stone) location and observation
only. For details, please refer to lithotripsy machine accompanying manuals.
To enter the mode: tap [Middle Line] in the iNeedle menu.
The middle line is a vertical dotted line located in the middle of the screen, the position and
direction of which cannot be changed.
There is a mark icon of “×” located on the middle line which can be moved up and down
along the line by rolling the track ball.
The depth of the mark is displayed in the image parameter area of the screen.
13.4 eSpacial Navi
13.4.1 Overview
The eSpacial Navi function builds up the connection between the ultrasound system and the
processed needles. The needle position appears on the image in real time. Meanwhile, the virtual
needle mark guides the needle path on the ultrasound image. Based on the magnetic induction
technology, the eSpacial Navi function aids in and enhance the ultrasound needle guidance.
L11-3VNs and L12-3VNs support the eSpacial Navi function.
Ultrasound images should be referenced during the
whole process of needle guidance.
The magnetizer should be used with the needle cap.
Disinfect the magnetizer after use.
The needle cap is a sterile, single use device. To
maintain procedural sterility, it is important that the
needle cap is isolated from non-sterile objects.
