Mindray TE7T User Manual

13-6 Probes and Biopsy
13.1.3 Orientation of the Ultrasound Image and the Probe
Head
The orientation of the ultrasound image and the probe are shown below. The “Mark” side of the
ultrasound image on the display corresponds to the mark side of the probe; for the laparoscopic
probe, the probe orientation starting side is located on the end of the distal tip away from the
handle. Check the orientation prior to the examination (using a linear probe as an example).
13.1.4 Operating Procedures
This section describes the general procedures for operating the probe. The proper clinical
technique to use for operating the probe should be selected on the basis of specialized training
and clinical experience.
Operating procedures (with biopsy function):
Orientation mark
Mark
