13-36 Probes and Biopsy
2. Select a proper needle-guided bracket, and match the groove with the tab of the transducer.
Mount the bracket onto the transducer.
3. Screw the pinch nut of the needle-guided bracket to confirm that the needle-guided bracket is
properly installed on the transducer.
4. Select the appropriate guiding block, and fit it into the groove on the angle block.
5. Screw the nut on the guiding block to secure the guiding block with the needle-guided bracket.
6. Insert the needle of the same specification with that of the guiding block into the guiding hole.
NGB-018
1. Put the sterile probe sheath on.
2. Select a suitable needle-guided bracket and match the groove to the tab of the transducer.
Mount the bracket onto the transducer. The needle-guided brackets may be different from
each other, but the methods are the same.
3. Screw the pinch nut of the needle-guided bracket to ensure that the needle-guided bracket is
properly installed on the transducer.
4. Select a suitable guiding block and push it into the groove above the angle block.
5. Screw the block's nut to secure the block.
6. Insert a biopsy needle with the same specification as that of the guiding block into the guiding
block hole.
NGB-034
1. Put on the sterile probe sheath.
