2-10 System Overview
No.
Name
Function
<1>
Touch screen and display
Operator-system interface or control; displays the image
and parameters during the scan.
: Battery status indicator.
 Charging status:
It illuminates in orange when batteries are charging;
It illuminates in green when batteries are charged fully.
 Discharging status:
It illuminates in green color when the power of the
batteries is sufficient;
It blinks in orange color for low battery power.
: AC indicator
The indicator is green at AC supply.
The indicator is off when batteries are supplied without
AC supply.
: Standby indicator.
Standby: blinking in orange.
Other status: light off.
<2>
Telescoping handle
Used for moving the system occasionally.
<3>
Intra-cavity probe holder
Used for placing the probe.
<4>
Probe locking switch
Locks or unlocks the probe connecting with the main unit.
<5>
Probe port
Connects a probe to the main unit.
<6>
Probe holder
Used for placing the probe.
<7>
Kensington lock
Locks the main unit to the trolley in case of loss.
<8>
Power inlet
Connects with the power adapter.
<9>
Serial port for connecting
ECG
Connects with the ECG module
<10>
HDMI
Used for extending the monitor.
<11>
USB ports
Connects USB devices.
<12>
Network port
Connects to network.
NOTE:
Mindray recommends using Category 2-certified HDMI output cables (marked as "High
Speed”) according to HDMI 1.3 standard for a good output effect. Otherwise, abnormal
display effect may result. You can use a HDMI-to-DVI adapter for outputting to a
display with DVI input.
When connecting TE7/TE7T/TE7S/TE7 Pro/TE7 Super/TE5/TE5T/TE5S/TE5 Pro/TE5
Super with an external display or recording devices via HDMI, choose a right output
setting resolution ([Setup] ->[System] ->[Peripheral] -> [Display]), and please make
sure the scan rate of 60Hz progressive is supported by the external device, otherwise
malfunction may result.
