Quick Reference Guide
V
V
V
c. Select Temporary Edit
d. Select waveform area to adjust waveform
e. Select new waveform parameter from list or select Off to remove
waveform
f. Select tile to adjust numeric parameter
g. Select new numeric parameter from list or select Off to remove numeric
parameter
h. Select Accept to save settings and return to the Display Setup tab
i. Select Accept to return to the main screen
Note: The first waveform is always ECG lead and HR is always located in the first
digital tile in the display selection.
Panorama® Central Station Interface: Digital and waveform display
selections on the Panorama Central Station, WorkStation, and ViewStation are
independent of the V12 or V21 bedside monitor.
HISTORY
List Trends
The List tab stores 3000 trend sets on a patient.
To display and adjust List trends on a patient on the V12 or V21 bedside
monitor:
a. Select History in the Navigation Area
b. Select List Trends tab
c. Select Display Group to specify trend category or select Custom
Configuration for user defined parameters to be displayed
d. Select Accept to save settings
e. Select Display Interval to specify the time interval list trends are to be
displayed
f. Select Accept to save settings
g. Select Done to return to the main screen
To print List trends on a patient at the V12 or V21 bedside monitor:
a. Select History in the Navigation Area
