13
3-3-4. Torque Setting
Set the maximum torque displayed.
Use the keys to change the torque
on the lower display to the required value.
* Enter value (2) on the calibration certificate sheet. (No
decimal point)
For example, if the maximum indication is 100.00 N·m,
set to [10000].
: Alters the value of the digit to be
altered.
: Selects the digit to be altered.
: Cancels the setting and returns to
measurement mode.
: Registers the value displayed and
proceeds to the next step.
Press the key after setting.
New torque value
To actual torque
setting
Registered torque
value
New torque value
To Next Page
