Minebea OPT-563B - 4 Function Mode; Selecting Function Mode

20
4. Function Mode
4-1. Selecting Function Mode
Function mode can be selected from measurement mode as follows.
appears in the upper part when the
key is depressed for approximately 2 seconds in
measurement mode.
The upper display reads when the
key is pressed.
Use the keys to select the required
function number on the upper display.
: Alters the value of the digit to be altered.
: Selects the digit to be altered.
: Cancels the setting and returns to
measurement mode.
: Registers the value displayed and
proceeds to the next step.
Press the key after setting.
The lower display changes to display the function
details.
Use the keys to select the required
function number on the lower display.
The upper display reads when the
key is pressed, indicating that function registration
is complete.
Press the key to exit function mode and return to
measurement mode.
Measurement mode
Value set
Value registered
To measurement mode
Value set
