4-2. Function List
Function No. Item
Setting
value
Details
F-01 Decimal place
●0 No decimal point
1 1000.0
2 100.00
3 10.000
4 1.0000
F-02 Torque display units
●0 N·m
1 kN·m
2 V
F-04 Display cycles
0 4 cycles/s
●1 20 cycles/s
F-05 Torque analog filter
0 1 Hz
1 10 Hz
2 30 Hz
3 50 Hz
4 100 Hz
5 300 Hz
6 500 Hz
●7 1 kHz
F-06 Torque digital filter
00~88
No. of moving-average samples = 2
m
＋2
n
m: 10
1
setting, n: 10
0
setting
●00
F-07 Rotation speed analog filter
0 1 Hz
●1 10 Hz
F-08 Rotation speed digital filter
00~88
No. of moving-average samples = 2
m
＋2
n
m: 10
1
setting, n: 10
0
setting
●00
F-09
Torque stabilization filter
No. of averaging
0 No. of moving-average samples: 1
1 No. of moving-average samples: 2
2 No. of moving-average samples: 4
3 No. of moving-average samples: 8
4 No. of moving-average samples: 10
5 No. of moving-average samples: 12
●6 No. of moving-average samples: 14
7 No. of moving-average samples: 16
8 No. of moving-average samples: 32
F-10
Torque stabilization filter
Time width setting
000~999
Unit: 10 ms
000: Torque stabilization filter off
●000
F-11
Torque stabilization filter
Data width setting
00~99
Unit: DIGIT
00: Torque stabilization filter off
●20
