17
3-3-8. Calibration End
Displays after span calibration ends.
Press the key to exit calibration mode.
The system switches to measurement mode and the data set is registered.
The calibration values (zero point and span) will not be entered unless the procedure is performed in sequence
up to this step.
Calibration can be performed only in the counter-clockwise torsional direction.
The A/Z function is canceled once calibration is completed.
Measurement
mode
To Next Page
