22
Function No. Item
Setting
value
Details
F-15
Rotation speed stabilization
filter
No. of averaging
0 No. of moving-average samples: 1
1 No. of moving-average samples: 2
2 No. of moving-average samples: 4
3 No. of moving-average samples: 8
4 No. of moving-average samples: 10
5 No. of moving-average samples: 12
●6 No. of moving-average samples: 14
7 No. of moving-average samples: 16
8 No. of moving-average samples: 32
F-16
Rotation speed stabilization
filter
Time width setting
000~999
Unit: 10 ms
000: Rotation speed stabilization filter off
●000
F-17
Rotation speed stabilization
filter
Data width setting
00~99
Unit: DIGIT
00: Rotation speed stabilization filter off
●20
F-18 Key lock
0000
~1111
●0000
0: Off
1: On
10
0
digit:
10
1
digit:
10
2
digit:
10
3
digit:
F-19 Polarity change
●0
Torque in counter-clockwise direction is
positive.
1 Torque in clockwise direction is positive.
F-20 CHECK value
0~20
Refer to Section 9-2-3.
●16
F-21
Torque analog output
Max. display value
1~99 999
Unit: DIGIT
●10 000
F-22
Rotation speed analog output
Max. display value
1~27 500
Unit: DIGIT
●25 000
F-23 Rotation direction polarity
● 0 +
1 -
F-24
Rotation detection input signal
format
● 0 Off
1 Measured using 2 rotation detectors
2
Measured using 1 rotation detector.
Rotation direction detected using external
input signal
3
Measured using 1 rotation detector.
Rotation direction cannot be detected.
