23
Function No. Item
Setting
value
Details
F-25 No. of rotation detection gears
●0 120
1 240
2 360
F-26
Selecting A/Z data save
destination
●0 RAM
1 EEPROM
F-30 RS-232C operating mode
●0 Command mode
1 Stream mode
F-31 RS-232C stream output target
●0 Torque display data
1 Input torque A/D data
2 Rotation speed display data
3 Frequency data
F-32
RS-232C/RS-422/RS-485
Baud rate
0 1,200 bps
1 2,400 bps
2 4,800 bps
●3 9,600 bps
4 19,200 bps
5 38,400 bps
6 57,600 bps
7 115,200 bps
F-33
RS-232C/RS-422/RS-485
Data bit length
●0 7 bit
1 8 bit
F-34
RS-232C/RS-422/RS-485
Parity bit
0 None
●1 Odd
2 Even
F-35
RS-232C/RS-422/RS-485
Stop bit
●0 1 bit
1 2 bit
F-36
RS-232C/RS-422/RS-485
Terminator
0 CR
●1
CR＋LF
F-37
RS-232C/RS-422/RS-485
Decimal point
●0 No
1 Yes
F-38 RS-422/485 address
00~31
●00
F-39 RS-422/485 selection
●0 RS-422
1 RS-485
F-40 RS-485 data delay time
000~999
Unit: 10 ms
Can be set in range 0~9.99 s.
●001
