Minebea OPT-563B - Page 26

24
Function No. Item
Setting
value
Details
F-41
PROFIBUS
Station No.
000~125
●000
F-42
CANopen
Node ID
001~127
●001
F-43
CANopen
Baud rate
0 10 kbps
1 20 kbps
2 50 kbps
3 100 kbps
4 125 kbps
5 250 kbps
6 500 kbps
7 800 kbps
●8 1 Mbps
F-45
CANopen
PDO output frequency
0~100
0: Off
Unit: 1 ms
●100
F-50 Maintenance 1 00000 0~99 999 (Do not use)
F-51 Maintenance 2 00000 0~99 999 (Do not use)
F-55 Calibration prohibited 0000
0: Calibration permitted
1: Calibration prohibited
10
0
digit: Calibration data 1
10
1
digit: Calibration data 2
10
2
digit: Calibration data 3
10
3
digit: Calibration data 4
F-56 Symmetry correction clear 0
Clear data corrected using symmetry
correction function.
F-57
Clearing counter-clockwise
linearization correction
0
Clear data corrected using linearization
correction function. (Counter-clockwise
direction)
F-58
Clearing clockwise linearization
correction
0
Clear data corrected using linearization
correction function. (Clockwise direction)
F-59 Calibration data selection
●0 Calibration data 1
1 Calibration data 2
2 Calibration data 3
3 Calibration data 4
F-60 Calibration 1 Increment 1 Datum value (initial value)
F-61
Calibration 1 Maximum display
value
10000 Datum value (initial value)
F-62
Calibration 1 Actual torque
value
10000 Datum value (initial value)
F-63 Calibration 1 ZERO A/D 0x1FFFF Datum value (initial value)
F-64 Calibration 1 +SPAN A/D 0x3AAAA Datum value (initial value)
F-65 Calibration 1 -SPAN A/D 0x5555 Datum value (initial value)
F-66
Calibration 1 ZERO frequency
conversion value
10000 Datum value (initial value)
F-67
Calibration 1 +SPAN frequency
conversion value
15000 Datum value (initial value)
F-68
Calibration 1 -SPAN frequency
conversion value
5000 Datum value (initial value)
