Minebea OPT-563B - Page 27

25
Function No. Item
Setting
value
Details
F-70 Calibration 2 Increment 1 Datum value (initial value)
F-71
Calibration 2 Maximum display
value
10000 Datum value (initial value)
F-72
Calibration 2 Actual torque
value
10000 Datum value (initial value)
F-73 Calibration 2 ZERO A/D 0x1FFFF Datum value (initial value)
F-74 Calibration 2 +SPAN A/D 0x3AAAA Datum value (initial value)
F-75 Calibration 2 -SPAN A/D 0x5555 Datum value (initial value)
F-76
Calibration 2 ZERO frequency
conversion value
10000 Datum value (initial value)
F-77
Calibration 2 +SPAN frequency
conversion value
15000 Datum value (initial value)
F-78
Calibration 2 -SPAN frequency
conversion value
5000 Datum value (initial value)
F-80 Calibration 3 Increment 1 Datum value (initial value)
F-81
Calibration 3 Maximum display
value
10000 Datum value (initial value)
F-82
Calibration 3 Actual torque
value
10000 Datum value (initial value)
F-83 Calibration 3 ZERO A/D 0x1FFFF Datum value (initial value)
F-84 Calibration 3 +SPAN A/D 0x3AAAA Datum value (initial value)
F-85 Calibration 3 -SPAN A/D 0x5555 Datum value (initial value)
F-86
Calibration 3 ZERO frequency
conversion value
10000 Datum value (initial value)
F-87
Calibration 3 +SPAN frequency
conversion value
15000 Datum value (initial value)
F-88
Calibration 3 -SPAN frequency
conversion value
5000 Datum value (initial value)
F-90 Calibration 4 Increment 1 Datum value (initial value)
F-91
Calibration 4 Maximum display
value
10000 Datum value (initial value)
F-92
Calibration 4 Actual torque
value
10000 Datum value (initial value)
F-93 Calibration 4 ZERO A/D 0x1FFFF Datum value (initial value)
F-94 Calibration 4 +SPAN A/D 0x3AAAA Datum value (initial value)
F-95 Calibration 4 -SPAN A/D 0x5555 Datum value (initial value)
F-96
Calibration 4 ZERO frequency
conversion value
10000 Datum value (initial value)
F-97
Calibration 4 +SPAN frequency
conversion value
15000 Datum value (initial value)
F-98
Calibration 4 -SPAN frequency
conversion value
5000 Datum value (initial value)
F-99 Memory clear -
Returns function settings to default
settings.
