Minelab GPX-4500 User Manual

24
25
Auto Tune
Search
Mode
Soil /
Timings
Ground
Balance
Coil /
Rx
CancelTrackingSpecialDeep
Custom Enhance Fixed Double D
MNG
Threshold
Coil
Smart
Point
Search Mode
(pg. 28) Each Mode
has factory preset
settings to suit that
style of searching.
Search Modes can
also be customised
to suit different
detecting conditions.
Soil/Timings
(pg. 36) allows
you to change the
electronic pulses/
timings of the
detector to optimise
performance for
different soils and
target types.
Ground Balance
(pg. 38) reduces
the ground
noise caused by
mineralisation.
Coil/Rx (pg. 44)
allows you to
change the
transmit and
receive (Rx) fields
of the coil.
Auto Tune (pg. 33) automatically scans
a range of frequency channels to help
reduce electrical interference.
Coil Connector
Connects the coil to the control box.
Smart Point is a connection point
for the Quick-Trak button located on
the handle.
Threshold (pg. 34) is the background
sound produced by the detector. This
control increases / decreases the level
of the Threshold.
Front Control Panel Rear Control Panel
Function
Select
Setting
On/Off
Hold for FP
Setting (pg. 51)
Once a function
has been selected,
Setting allows you to
adjust its value.
Function Select
(pg. 50) scrolls up or
down through the list
of functions.
LCD
(Liquid Crystal Display)
Displays all the menu
functions and settings.
Now with backlight
(pg. 54).
Battery Connector
connects the control
box to the battery
and headphones.
On / Off (pg. 26)
turns the detector
on and allows you
to restore Factory
Presets.

Minelab GPX-4500 Specifications

General

Search Modes	General, Deep, Custom
Battery Life	Up to 12 hours
Ground Balance	Automatic and Manual
Display	LCD
Technology	MPS, DVT, SETA
Coil	11" Double-D Coil
Audio Output	Internal speaker, headphone jack
Battery	Lithium-ion
Waterproof	Coil is waterproof
Warranty	3 years
