Minelab GPX-4500 - Function Select; Setting

50
51
Function
Select
Setting
On/Off
Hold for FP
Function
Select
Setting
On/Off
Hold for FP
Navigation Arrows
Indicates which way
the setting can be
adjusted.
Function
Factory Preset
Indication
Indicates current
setting as a
Factory Preset.
Function Setting
(Visual Scale)
Function Setting
(Numerical)
Function Select Setting
Once a function has been selected
the Setting control accesses a settings
adjustment screen.
The Function Select control scrolls
through a list of functions.
Navigation Arrows
Indicates which way
the menu can scroll.
Title
Indicates what type
of function you are
viewing (universal or
mode dependant).
Functions
There are two
types of functions,
universal functions
(under the Main
Menu heading)
and mode specific
functions (under
the Search Mode
heading).
Function Setting
New Value Icon
Indicates the value
for this function has
been changed from
the Factory Preset.
Function
Select
Setting
On/Off
Hold for FP
