User Manual
Revised on 05/09/2022 Page 13
Level and Install
• Before installation, check the surface where the SmartCube is to be placed. It MUST be solid, flat
and level.
• For optimum performance of the cooling system, it is recommended that the level is checked in
both planes – see the Level Diagram below.
• If it is not level, remedial action must be taken to level the surface.
• For safety, secure or anchor the SmartCube to the floor using screws appropriate for the material
and thickness of the case good floor. Holes can be found in each front foot and covers are provided
for aesthetic purposes.
• Ensure the mains power cord and any other cables are not trapped under the unit.
• For more information, refer to the SmartCube Case Good Specifications manual available from your
Minibar representative or from the Minibar Systems website.
Typical level checks in both planes for optimum performance of the SmartCube. FRONT
VIEW SIDE VIEW
