Console Box Installation
Mount the Console Box to the SmartCube back using 2 Round
Philips Head screws (MB-NP-0027) and 1 Flat Philips Head
screw(MB-NP-0029).
Connect all cables back according to the wiring diagram and
then swith on the power supply unit.
