Minibar Systems SMARTCUBE SC-40T - Door Shelf Installation

User Manual
2021 Page 20
Door Shelf Installation
Slide the door sensor shelf (MB-MA-0035) into the
bottom support and connect it to the backpane
Screw the right side door shelf column using a Philips
head screw driver to secure the sensor shelves.
Slide the rack kit between the two door shelf columns
and engage into the side wall locking tabs.
