Signal ow of the miniDSPFlexEight (without DiracLive)
The audio signal ows from left to right in the above diagram:
1. One of the four stereo input sources is selected by the user.
2. The selected stereo signal is passed through the input channel processing blocks: level metering, input gain,
parametric EQ and FIR ltering.
3. The processed input channels are fed into a 2-in 8-out routing matrix that routes/mixes the two processed input
channels to the eight output channels.
4. Each output channel runs a comprehensive set of DSP functions: parametric EQ, crossovers, level metering, delay,
output gain and compressor.
The combination of the routing matrix and the crossover blocks on the output channels is what gives the
miniDSPFlexEight the ability to be used in many different system congurations.
