Power amplifier
Loudspeakers
MINIDSP.COM
MADE IN CHINA
DESIGNED IN HK
MODEL: FLEX EIGHT
INPUT: 12VDC/10W
GND
A 
C
DC 12V
SPDIF
TOSLINK
D
USB
PWR
RESET
2
1
4
3
6
5
8
7
miniDSP
Flex Eight
Left Right
Connecting a stereo amplier and speakers to the miniDSPFlexEight
Of course, more complex connections are possible using the additional outputs. In that case, the internal processing
will need to be set up using the miniDSPDeviceConsole. Refer to the Signal Flow and DSP Reference sections for
details.
Ensure all equipment is powered off when making audio connections.
Before playing audio for the rst time, turn the volume down using the front panel encoder. Increase it gradually after
audio playback starts.
Bluetooth audio
The miniDSPFlexEight includes the LDAC (https://www.sony.net/Products/LDAC/) ™ and aptX™ HD Bluetooth codecs
for high-delity Bluetooth™ audio.
Warning
Warning
