Plumbing Diagram (Part 1)
FIG. PART NUMBER DESCRIPTION QTY
A 011993-00000 BRAKE CALIPER 2
B 010829-00005 FITTING, MALE ELBOW 5/32 TUBE TO 1/8 MALE NPT 10
C 010842-00001 FITTING, 5/32 Y – TUBE TO TUBE 1
D 009070-1.500 CYLINDER, AIR 2-1/2 X 1-1/2 1
E 006296-00015 BUSHING, REDUCER PIPE 06-02 4
F 006296-00016 BUSHING, REDUCER PIPE 04-02 4
G 010935-00000 VALVE (CRAB) 1
G 006256-1.500 #8-32 X 1-1/2 SLOTTED 3
G 006144-00000 #8 LOCKWASHER 3
H 010825-00008 FITTING, 1/4 TUBE TO 1/4 MALE NPT 4
I 010829-00010 FITTING, MALE ELBOW 1/4 TUBE TO 1/4 MALE NPT 2
J 011525-00000 VALVE (STEERING) 1
J 006256-1.500 #8-32 X 1-1/2 SLOTTED 3
J 006144-00000 #8 LOCKWASHER 3
K 009070-7.000 CYLINDER, AIR 2-1/2 X 7 1
L 006019-00024 ELBOW, 90 DEG EXT PIPE 37 DEG 12-12 1
M 006000-00007 NIPPLE, PIPE 3/4 X 3 SCH 40 GALVANIZED 2
N 011526-00000 VALVE (TRAVEL) 1
N 006037-2.750 HHCS, 5/16-18 X 2-3/4 3
N 006148-00000 5/16 LOCKWASHER 3
O 006007-00023 CONNECTOR, 37 DEG MALE/PIPE 12-12 2
P 006024-00007 TEE, SWIVEL RUN 37 DEG 12-12 4
Q 006023-00008 ELBOW, 90 DEG/37 DEG MALE/FEM SWIVEL 12-12 2
R 006032-00006 END, HOSE 37 DEG FEM SWIVEL/BARBED 12 13
S 006021-00016 ELBOW, 45 DEG EXT PIPE/37 DEG 08-12 6
XX 010863-00000 TUBING, NYLON 1/4 BLACK SEMI-RIGID 34
YY 010861-00000 TUBING, NYLON 5/32 BLACK SEMI-RIGID 228
ZZ 003997-00000 HOSE, 3/4 ID, 200 PSI 215
