- 53 -
Form: MM-
4/A5SC Revised 07/13/16
50# (23kg) Rock Drill
0A9350-00000
When ordering replacement parts you need to furnish the model and serial number of the drill tool.
WARNING: Always disconnect the air supply before changing
steel or dismantling the tool for service or repair.
For maximum safety we advise the installation of a
shut-off valve at the end of the air line.
Specifications
Net Weight
51lbs. (23kg)
Blows Per Minute
2300
Chuck Size
7/8” x 4 1/4” (22.2mm x 107.9mm)
Air Inlet (NPT)
3/4” (19.1mm)
Air Consumption
92.2cfm (2.6m3/min)
