Minnich A-4SC - Air Motor 005392-00001

- 45 -
Form: MM-
A
4/A5SC Revised 07/13/16
Air Motor
005392-00001
FIG. PART NUMBER DESCRIPTION QTY
1* 005392-01-02 SHAFT SEAL 1
2* 005392-01-03 O-RING 1
3* 005392-01-04 BEARING, DRIVE END 1
4 005392-01-05 DOWEL PIN 4
5* 005392-00003 BODY GASKET 2
6 005392-01-08 KEY 1
7* 005392-00004 PUSH PIN 4
8* 005392-00005 VANE SPRING 8
9* 005392-00006 VANE 8
10* 005392-01-10 BEARING, DEAD END 1
11* 005392-00007 END CAP, GASKET 1
* 005392-01-13 FELT 1
005392-00002 SERVICE KIT 1
* Parts included in service kit (005392-00002).
