Minnich A-4SC - Marker Assembly A10940-00000

- 39 -
Form: MM-
A
4/A5SC Revised 07/13/16
FIG. PART NUMBER DESCRIPTION QTY
A A10953-00000 WELDM’T SPRAY CAN HOLDER 1
B 008761-00000 CYLINDER, AIR .562 X .5 1
C 010826-00001 FITTING, 5/32 TUBE TO 10-32 UNF 1
D 008764-00000 CYLINDER ROD EYE 1
D 011914-00004 HOSE, 1/4 HYDRAULIC AR17 .25
E 010941-00000 EYEBOLT 1
F 008764-00000 CYLINDER ROD EYE 1
G 006036-1.250 HHCS, 1/4-20 X 1-1/4 GR.5 1
G 006402-00000 LOCKNUT 1/4-20 1
H 010943-00000 LEVER BLANK 1
I 008764-00000 CYLINDER ROD EYE 1
J 006654-00000 NUT, HEX #10-24 NC THREAD 1
K 010954-00000 EYEBOLT 1
L 010942-00000 EYEBOLT 1
M 006256-0.250 RHMS, #8-32 X 1/4 SLOTTED 2
M 006144-00000 LOCKWASHER, #8 2
N 010955-00000 DRAW LATCH 1
O 010861-00000 TUBING, NYLON 5/32 BLACK SEMI-RIGID 120
