Minnich A-4SC - Pointer & Marker 0 A6964-00000

- 40 -
Form: MM-
A
4/A5SC Revised 07/13/16
FIG. PART NUMBER DESCRIPTION QTY
A A10940-00000 ASSY, MARKER 1
B 012006-00000 TUBE, EXTENSION 1
C 0A6959-00000 WELDM’T TUBE 1
C 006038-1.250 HHCS, 3/8-16 X 1-1/4 GR.5 2
C 006072-00000 NUT HEX 3/8-16 2
D 006038-1.250 HHCS, 3/8-16 X 1-1/4 GR.5 4
D 006072-00000 NUT HEX 3/8-16 4
E 0A6961-00000 WELDM’T ADJUSTMENT 1
F 0A6965-00000 WELDM’T GUIDE BRACKET 1
G 002042-00000 ISOLATOR 1
G 006071-00000 NUT, HEX 5/16-18 1
G 006148-00000 LOCKWASHER 5/16 1
H 008479-00001 PIN, TAB LOCK 1
I 006037-5.000 HHCS, 5/16-18 X 5 GR.5 1
I 006071-00000 NUT, HEX 5/16-18 1
I 006148-00000 LOCKWASHER 5/16 1
